TracoPower TXM 075-105 TXM SMPSU 5.15V DC 12A 60W Efficient Power Supply

TracoPower
Standard range
Order Code:

07-8452

Brand: TracoPower MPN: TXM 075-105
Qty Unit Price (Ex VAT)
1+ £40.78
5+ £39.56
10+ £38.34
25+ £36.70
50+ £35.07
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
2 in stock, despatched in 4 working days

TracoPower manufactures the TXM 075-105 SMPSU, a printed circuit board power supply unit delivering 5.15 V DC at 12 A with a 60 W output. This PSU with solder lugs is designed for PCB mount applications requiring reliable power in a compact form. Typically, it is used in industrial and commercial electronic devices needing stable low-voltage power solutions.
Type SMPSU
Connection Screw terminal
Dim (L x W x H) 129 x 99.0 x 38.0 mm
Height 38.0mm
Input voltage (max.) 264V AC
Length 129mm
Max. operating temperature (derating) 50°C
Max. output current 12A
Max. temperature 70°C
Min. input voltage 90V AC
Min. temperature -25°C
Misc Attribute 1 TXM 075-105
Misc Attribute 2 closed
No. of outputs 1
Operating temperature (max.) 70°C
Operating temperature (min.) -25°C
Output current (max.) - rounded 12A
Output current (min.) 0mA
Output voltage (max.) 5.15V DC
Output voltage (min.) 4.85V DC
Power 60W
Weight 380g
Width 99.0mm
