TracoPower TXL 025-3.3S Compact SMPSU 3.3V 6A 25W Metal Casing EMC Compliant

TracoPower
Order Code:

07-8426

Brand: TracoPower MPN: TXL 025-3.3S
Qty Unit Price (Ex VAT)
1+ £31.49
5+ £30.56
10+ £29.61
25+ £28.34
50+ £27.08
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 28/12/2025

The TracoPower TXL 025-3.3S is a PCB-mounted power supply unit delivering 3.3 V DC at 6 A with a power rating of 25 W. It features a switched-mode power supply design and is equipped with solder lugs for easy PCB equipping. This power supply is typically used in applications requiring reliable and efficient power conversion on a circuit board.
Dim (L x W x H) 28.5 x 51.0 x 93.0 mm
Height 93.0mm
Input Voltage 85 - 264V AC
Input voltage (max.) 264V AC
Length 28.5mm
Max. operating temperature (derating) 45°C
Max. output current 6A
Max. temperature +70°C
Min. input voltage 85V AC
Min. operating temperature (derating) -20°C
Min. temperature -10°C
Misc Attribute 1 Switched Mode
Misc Attribute 3 closed
MTBF 250000h
Number of Outputs 1
Operating temperature (max.) 70°C
Output current (max.) - rounded 6A
Output current (min.) 0mA
Output voltage (max.) 3.3V DC
PFC Yes
Power 25W
Type SMPSU
Width 51.0mm
