TracoPower TSR 2-2490 DC/DC Converter 24V DC to 9V DC 2A SIL Casing

TracoPower
Standard range
Order Code:

07-8422

Brand: TracoPower MPN: TSR 2-2490
Qty Unit Price (Ex VAT)
1+ £13.00
5+ £12.61
10+ £12.22
25+ £11.69
50+ £11.18
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
10 in stock, despatched in 4 working days

The TracoPower TSR 2-2490 is a DC/DC converter capable of transforming 24 V DC input to a 9 V DC output with a current of 2 A. This product is a direct current converter featuring a single output suitable for providing reliable power in compact electronic applications. It is ideal for use in telecommunications, industrial electronics, and portable equipment.
Type DC/DC converter (print)
Connection Solder pins
Dim (L x W x H) 14 x 14.2 x 7.5 mm
Efficiency (max.) 95%
Enclosure SIL
Height 7.5mm
Input voltage (max.) 3.63V DC
Length 14mm
Max. output current 2A
Min. input voltage 2.97V DC
Misc Attribute TSR 2-2490
No. of outputs 1
Nominal voltage 24V DC
Operating temperature (max.) 85°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 2A
Output voltage (max.) 9V DC
Output voltage (min.) 9V DC
Output voltages 9V DC
Weight 2.6g
Width 14.2mm
