TracoPower TSR 1-4865WI DC/DC converter 1 output 1A 7W single unit

TracoPower TSR 1-4865WI is a direct current (DC) to DC converter designed to deliver robust power conversion in compact applications. This converter features a single output with a maximum current of 1 ampere and a power capacity of 7 watts, making it suitable for a variety of electronic devices requiring precise voltage regulation. As a print converter, it is optimised for integration into circuit boards where space and efficiency are crucial. The TSR 1-4865WI is ideal for use in power management applications within telecommunications, data acquisition systems, and industrial electronics, where reliable power conversion with minimal heat generation is essential. Its design ensures high performance in environments demanding consistent voltage levels from varying input sources.

Connection	Solder pins
Content	1
Dimensions	(L x W x H) 8.6 x 12.1 x 17.5 mm
Efficiency (max.)	88%
Height	17.5mm
Length	8.6mm
Max. output current	1A
Maximum Input Volage	72V DC
Maximum Operating Temperature	80°C
Minimum Input Volage	9V DC
No. of outputs	1
Operating temperature (min.)	-40°C
Output current (max.) - rounded	1A
Output voltage (max.)	6.5V DC
Output voltage (min.)	6.5V DC
Power	7W
Product Type	DC/DC converter (print)
PSU features	DC-to-DC converter
Type	TSR 1-4865WI
Weight	5.5g
Width	12.1mm
