TracoPower TSR 1-4850WI DC/DC converter 1 A 5 W 1 output

TracoPower TSR 1-4850WI is a high-performance DC-DC converter designed to deliver up to 1 A of current with a power rating of 5 W. The compact unit provides a single output, making it an ideal solution for space-constrained applications where efficient power conversion is essential. With its wide input voltage range and high efficiency, the TSR 1-4850WI is particularly suited for use in industrial automation systems, telecommunications equipment, and embedded computing applications. This converter is engineered to handle demanding environments, ensuring robust performance and reliability across various operational conditions. The unit is packaged for print mounting, facilitating easy integration into existing circuit designs.

Connection	Solder pins
Content	1
Dimensions	(L x W x H) 8.6 x 12.1 x 17.5 mm
Efficiency (max.)	87%
Height	17.5mm
Length	8.6mm
Max. output current	1A
Maximum Input Volage	72V DC
Maximum Operating Temperature	80°C
Minimum Input Volage	9V DC
No. of outputs	1
Operating temperature (min.)	-40°C
Output current (max.) - rounded	1A
Output voltage (max.)	5.0V DC
Output voltage (min.)	5.0V DC
Power	5W
Product Type	DC/DC converter (print)
PSU features	DC-to-DC converter
Type	TSR 1-4850WI
Weight	5.5g
Width	12.1mm
