TracoPower TSR 1-48150WI DC/DC converter 1x1A 15W

TracoPower TSR 1-48150WI is a high-efficiency DC-DC converter designed for reliable performance in various industrial applications. This direct current converter supports a maximum output of 1 ampere and 15 watts, making it an ideal choice for engineers requiring a robust power conversion solution in compact electronic circuits. With its single output capability, the TSR 1-48150WI is well-suited for use in telecommunications equipment, industrial automation systems, and battery-powered devices where efficient power regulation is critical. Designed for easy integration into printed circuit boards, this converter ensures stable electrical performance with minimal thermal output. The product is supplied as a single piece and reflects TracoPower's commitment to quality and precision in power electronics.

Connection	Solder pins
Content	1
Dimensions	(L x W x H) 8.6 x 12.1 x 17.5 mm
Efficiency (max.)	93%
Height	17.5mm
Length	8.6mm
Max. output current	1A
Maximum Input Volage	72V DC
Maximum Operating Temperature	80°C
Minimum Input Volage	21V DC
No. of outputs	1
Operating temperature (min.)	-40°C
Output current (max.) - rounded	1A
Output voltage (max.)	15.0V DC
Output voltage (min.)	15.0V DC
Power	15W
Product Type	DC/DC converter (print)
PSU features	DC-to-DC converter
Type	TSR 1-48150WI
Weight	5.5g
Width	12.1mm
