TracoPower TSR 1-2433SM DC/DC Converter 24V to 15V 1A SMD Short-Circuit Proof

TracoPower
Order Code:

07-8412

Brand: TracoPower MPN: TSR 1-2433SM
Qty Unit Price (Ex VAT)
1+ £7.73
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 28/12/2025

The TracoPower TSR 1-2433SM is a DC/DC converter with an input of 24 V DC and an output of 15 V DC at 1 A. This surface mount device features a single output, making it suitable for applications requiring efficient voltage conversion. It is commonly used in industrial electronics and embedded systems for reliable power regulation.
Connection SMD
Dim (L x W x H) 15.2 x 11.8 x 7.6 mm
Efficiency (max.) 91%
Enclosure SMD
Height 7.6mm
Input voltage (max.) 36V DC
Length 15.2mm
Max. output current 1A
Min. input voltage 18V DC
Misc Attribute 1 TSR 1-2433 SM
Nominal Voltage 24V DC
Number of Outputs 1
Operating temperature (max.) 85°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 1A
Output voltage (max.) 3.3V DC
Output voltage (min.) 3.3V DC
Output voltages 15V DC
Type DC/DC converter (SMD)
Width 11.8mm
