TracoPower TSP-REM360 EX Rail-Rail Redundancy 360W 15000mA 1 Output

The TracoPower TSP-REM360 EX is a rail-mounted redundancy power supply unit designed for industrial applications and providing 360 W with a current of 15000 mA. This single-output DIN rail power supply module is perfect for ensuring reliable power in demanding environments. It is widely used in settings requiring robust and efficient power delivery, such as control panels and industrial automation systems.

Type	Rail mounted redundancy (DIN)
Nominal value output current 1	15A
Number of Outputs	1
Power Rating	360W
Depth	115.0mm
Dimensions (L x W x H)	115.0 x 35.0 x 110.0mm
Height	110.0mm
Max. output current 1	15000mA
Maximum input voltage [DC]	+24.0V
Maximum Operating Temperature	70°C
Maximum Temperature	70°C
Min. operating temperature (derating)	40°C
Min. temperature	-25°C
Minimum Input Voltage [DC]	+24.0V
Nominal value output voltage 1 [DC]	+24.0V
Operating temperature (min.)	-25°C
Type of electric connection	Screw terminal
Weight	500g
Width	35.0mm
