TracoPower TPP 15-124-J SMPSU 24V DC 0.62A 15W Compact Power Supply

TracoPower
Standard range
Order Code:

07-8338

Brand: TracoPower MPN: TPP 15-124-J
Qty Unit Price (Ex VAT)
1+ £31.08
5+ £30.15
10+ £29.22
25+ £27.97
50+ £26.74
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
3 in stock, despatched in 4 working days

The TracoPower TPP 15-124-J is a printed circuit board power supply unit offering 24 V DC output at 0.62 A with a 15 W power rating. It features a PCB mount design with solder lugs, suitable for efficient and compact electronic applications. This SMPSU is commonly used in industrial and automation systems requiring reliable power conversion.
Type SMPSU
Connection Connector
Dim (L x W x H) 71.7 x 28.9 x 20.9 mm
Height 20.9mm
Input voltage (max.) 264V AC
Length 71.7mm
Max. operating temperature (derating) 70°C
Max. output current 0.62A
Max. temperature 85°C
Min. input voltage 85V AC
Min. temperature -40°C
Misc Attribute 1 TPP 15-124-J
Misc Attribute 2 closed
No. of outputs 1
Operating temperature (max.) 85°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 620mA
Output current (min.) 0mA
Output voltage (max.) 24V DC
Output voltage (min.) 24V DC
Power 15W
Weight 48g
Width 28.9mm
