TracoPower TMR 4-2411WI DC/DC Converter 5V 0.8A 4W

TracoPower
Standard range
Order Code:

07-8300

Brand: TracoPower MPN: TMR 4-2411WI
Qty Unit Price (Ex VAT)
1+ £12.28
5+ £12.21
10+ £11.63
25+ £11.38
50+ £11.19
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
6 in stock, despatched in 4 working days

The TracoPower TMR 4-2411WI is a DC/DC converter providing 5 V DC output at 0.8 A with a power rating of 4 W. It is suitable for PCB mountings and uses solder lugs, making it ideal for integration into printed circuit board power supply units. The unit is typically used in applications where a compact, reliable power solution is needed for circuit board setups.
Type DC/DC converter
Connection Solder pins
Dim (L x W x H) 21.8 x 9.3 x 15.2 mm
Efficiency (max.) 79%
Height 15.2mm
Input voltage (max.) 36.0V DC
Insulation voltage 1600V DC
Length 21.8mm
Max. output current 0.8A
Min. input voltage 9.0V DC
Misc Attribute 1 TMR 4-2411WI
Misc Attribute 2 closed
No. of outputs 1
Operating temperature (max.) 70°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 800mA
Output current (min.) 0mA
Output voltage (max.) 5V DC
Output voltage (min.) 5V DC
Output voltages 5.0V DC
Power 4W
Weight 4.8g
Width 9.3mm
