TracoPower TMDC 20-7215H DC/DC converter 830mA 20W 1 output

TracoPower TMDC 20-7215H is a high-performance DC-DC converter designed for efficient power conversion in demanding applications. With a capacity to deliver 830 mA at a power rating of 20 W, this device features a single output, making it suitable for driving critical loads where precise power regulation is required. Engineered for reliability, the TMDC 20-7215H is particularly effective in industrial, telecommunications, and transportation systems where stable power supply is crucial. Its robust construction and efficient power conversion capabilities ensure optimal performance across a range of environmental conditions, providing engineers with a dependable solution for maintaining consistent power delivery in their designs.

Connection	Screw terminal
Content	1
Dimensions	(L x W x H) 96.0 x 54.0 x 23.3 mm
Efficiency (max.)	88%
Height	23.3mm
Input voltage (max.)	160V DC
Insulation Voltage	3000V DC
Length	96.0mm
Max. output current	830mA
Min. input voltage	80V DC
No. of outputs	1
Operating temperature (max.)	85°C
Operating temperature (min.)	-40°C
Output current (max.) - rounded	830mA
Output voltage (max.)	24.0V DC
Output voltage (min.)	24.0V DC
Power	20W
Product Type	DC/DC converter
PSU features	DC-to-DC converter
Type	TMDC 20-7215H
Weight	107g
Width	54.0mm
