TracoPower TMDC 20-2418 DC/DC Converter Module 24V-48V 420mA 20W

TracoPower
Order Code:

07-8248

Brand: TracoPower MPN: TMDC 20-2418
Qty Unit Price (Ex VAT)
1+ £52.06
5+ £50.50
10+ £48.93
25+ £46.85
50+ £44.76
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 28/12/2025

The TracoPower TMDC 20-2418 is a DC/DC converter module that converts 24 V DC to 48 V DC at a current of 420 mA with a power output of 20 W. It is ideal for use in industrial and telecommunications applications where efficient voltage conversion is required. The module features a single output and compact design for easy integration into existing systems.
Connection Screw terminal
Dim (L x W x H) 54 x 96 x 23.3 mm
Efficiency (max.) 89%
Height 23.3mm
Input voltage (max.) 36V DC
Insulation Voltage 2500V DC
Length 54mm
Max. output current 420mA
Min. input voltage 9V DC
Misc Attribute 1 20-2418 TMDC
Nominal Voltage 24V DC
Number of Outputs 1
Operating temperature (max.) 90°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 420mA
Output voltage (max.) 48V DC
Output voltage (min.) 48V DC
Output voltages 48V DC
Power 20W
Type DC/DC converter (module)
Width 96mm
