TracoPower TMDC 20-2415 DC/DC Converter 24V 835mA 20W 1 Output

TracoPower
Order Code:

07-8247

Brand: TracoPower MPN: TMDC 20-2415
Qty Unit Price (Ex VAT)
1+ £53.10
5+ £51.50
10+ £49.90
25+ £47.78
50+ £45.66
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 28/12/2025

The TracoPower TMDC 20-2415 is a DC/DC converter module with a single 24 V DC output rated at 835 mA and 20 W power. As a reliable current rectifier, it is designed to efficiently convert DC inputs to DC outputs. Typical applications include industrial automation systems and telecommunications equipment where stable power supply is essential.
Connection Screw terminal
Dim (L x W x H) 54 x 96 x 23.3 mm
Efficiency (max.) 91%
Height 23.3mm
Input voltage (max.) 36V DC
Insulation Voltage 2500V DC
Length 54mm
Max. output current 835mA
Min. input voltage 9V DC
Misc Attribute 2 TMDC20-2415
Nominal Voltage 24V DC
Number of Outputs 1
Operating temperature (max.) 90°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 835mA
Output voltage (max.) 24V DC
Output voltage (min.) 24V DC
Output voltages 24V DC
Power 20W
Type DC/DC converter (module)
Width 96mm
