TracoPower TMDC 20-2412 DC/DC Converter 24V to 12V 1.67A 20W 1 Output

TracoPower
Order Code:

07-8246

Brand: TracoPower MPN: TMDC 20-2412
Qty Unit Price (Ex VAT)
1+ £52.05
5+ £50.49
10+ £48.92
25+ £46.84
50+ £44.76
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 28/12/2025

The TracoPower TMDC 20-2412 is a DC/DC converter module featuring 24 V DC input and 12 V DC output with a current capacity of 1.67 A and power rating of 20 W. It is designed for high-efficiency power conversion in industrial and telecommunications applications. This single-output unit ensures reliable voltage regulation and energy efficiency in a compact form factor.
Connection Screw terminal
Dim (L x W x H) 54 x 96 x 23.3 mm
Efficiency (max.) 91%
Height 23.3mm
Input voltage (max.) 36V DC
Insulation Voltage 2500V DC
Length 54mm
Max. output current 1.67A
Min. input voltage 9V DC
Misc Attribute 2 TMDC20-2412
Nominal Voltage 24V DC
Number of Outputs 1
Operating temperature (max.) 90°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 1.67A
Output voltage (max.) 12V DC
Output voltage (min.) 12V DC
Output voltages 12V DC
Power 20W
Type DC/DC converter (module)
Width 96mm
