TracoPower TIB 080-124 DIN-Rail SMPSU 28V 3.4A 80W Suitable for Germany

TracoPower
Order Code:

07-8231

Brand: TracoPower MPN: TIB 080-124
Qty Unit Price (Ex VAT)
1+ £76.54
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 14/12/2025

The TracoPower TIB 080-124 is a 28 V DC, 80 W switch mode power supply unit ideal for PCB mounting with solder lugs. It offers reliable power conversion and is well-suited for integration into printed circuit board setups. Typical applications include industrial electronic equipment and systems that require stable DC power on a DIN rail.
Connection Screw terminal
Dim (L x W x H) 98.6 x 32 x 114.2 mm
Height 114.2mm
Input voltage (max.) 264V AC
Length 98.6mm
Max. operating temperature (derating) 60°C
Max. output current 3.4A
Min. input voltage 85V AC
Misc Attribute 2 closed
Number of Outputs 1
Operating temperature (max.) 70°C
Operating temperature (min.) -25°C
Output current (max.) - rounded 3.4A
Output current (min.) 0mA
Output voltage (max.) 28V DC
Output voltage (min.) 23.5V DC
Power 80W
Type SMPSU
Width 32mm
