TracoPower THM 15-2423 DC/DC converter 500mA 15W 2 outputs

TracoPower THM 15-2423, identified by the manufacturer part number 02050006436509, is a robust DC-DC converter designed to deliver a continuous output of 15 watts with a maximum load current of 500 mA, distributed over two outputs. This compact unit is engineered for high reliability in applications where isolated power is required, such as in industrial, transportation, and medical equipment. Featuring a design suitable for direct integration into printed circuit boards, this converter effectively transfers and rectifies DC voltage to meet precise energy specifications. The THM 15-2423 is particularly valued for its efficiency and reliability in environments with stringent electromagnetic compatibility and thermal performance requirements. Employing advanced switching technology, it ensures stable and reliable operation across varied input voltage conditions.

Connection	Solder pins
Content	1
Dimensions	(L x W x H) 40.60 x 25.40 x 10.20 mm
Efficiency (max.)	90%
Height	10.20mm
Insulation Voltage	5000V AC
Length	40.60mm
Max. output current	500mA
Maximum Input Volage	36V DC
Maximum Operating Temperature	85°C
Minimum Input Volage	18V DC
No. of outputs	2
Operating temperature (min.)	-40°C
Output current (max.) - rounded	500mA
Power	15W
Product Type	DC/DC converter (print)
Type	THM 15
Weight	24g
Width	25.40mm
