TracoPower THL 3-2415WISM DC/DC Converter 24V SMD Compact 3W 125mA

The TracoPower THL 3-2415WISM is a compact DC/DC converter designed for surface-mounting with an input and output voltage of 24 V DC, providing up to 125 mA and 3 W of power through a single output. Manufactured by TracoPower, this converter is ideal for applications requiring efficient energy conversion in compact spaces, such as telecommunications and industrial electronics. It features high reliability and precision, suitable for modern electronic systems requiring stable power supply solutions.

Connection	SMD
Dim	(L x W x H) 18.1 x 24 x 8 mm
Efficiency (max.)	80%
Enclosure	SMD
Height	8mm
Input voltage (max.)	3.63V DC
Insulation Voltage	1500V DC
Length	18.1mm
Max. output current	125mA
Min. input voltage	2.97V DC
Misc Attribute 2	THL3-2415WISM
Nominal Voltage	24V DC
Number of Outputs	1
Operating temperature (max.)	85°C
Operating temperature (min.)	-40°C
Output current (max.) - rounded	125mA
Output voltage (max.)	24V DC
Output voltage (min.)	24V DC
Output voltages	24V DC
Power	3W
Type	DC/DC converter (SMD)
Width	24mm
