TracoPower TEP 75-2412WI-CMF DC/DC Converter 24V to 12V 6.3A 75W 1 Output

TracoPower
Order Code:

07-8177

Brand: TracoPower MPN: TEP 75-2412WI-CMF
Qty Unit Price (Ex VAT)
1+ £187.85
5+ £182.22
10+ £176.58
25+ £169.07
50+ £161.56
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 25/01/2026

The TracoPower TEP 75-2412WI-CMF is a high-efficiency DC/DC converter module that converts 24 V DC to 12 V DC with an output current of 6.3 A and a power of 75 W. It is suitable for use in applications requiring reliable power conversion in industrial and telecommunications sectors. This module provides a single output and is known for its compact design and robust performance.
Connection Screw terminal
Dim (L x W x H) 85 x 61 x 38.8 mm
Efficiency (max.) 88%
Height 38.8mm
Input voltage (max.) 36V DC
Insulation Voltage 1600V DC
Length 85mm
Max. output current 6.3A
Min. input voltage 9V DC
Nominal Voltage 24V DC
Number of Outputs 1
Operating temperature (max.) 75°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 6.3A
Output voltage (max.) 12V DC
Output voltage (min.) 12V DC
Output voltages 12V DC
Power 75W
Type DC/DC converter (module)
Width 61mm
