TracoPower TEN 40-2412WIE DC/DC converter 40W 3.333A 1 output

TracoPower TEN 40-2412WIE is a reliable DC-DC converter designed for efficient energy transformation in electronic systems. Featuring a compact design, this print-mount converter delivers a power output of 40 watts and a steady current of 3.333 amperes, with a single output channel. Built to facilitate the conversion of direct current, this device is suitable for use in industrial, telecommunications, and transportation applications where stable voltage conversion is essential. The TEN 40-2412WIE is engineered to adhere to high-quality standards, ensuring its performance in environments that demand precision and reliability in power supply.

Power Rating	40W
Connection	Solder pins
Content	1
Dimensions	(L x W x H) 50.8 x 25.4 x 10.2 mm
Efficiency (max.)	92%
Height	10.2mm
Insulation Voltage	1600V DC
Length	50.8mm
Max. output current	3.333A
Maximum Input Volage	36V DC
Maximum Operating Temperature	85°C
Minimum Input Volage	9V DC
No. of outputs	1
Operating temperature (min.)	-40°C
Output current (max.) - rounded	3.33A
Output voltage (max.)	12.0V DC
Output voltage (min.)	12.0V DC
Power	40W
Product Type	DC/DC converter (print)
PSU features	DC-to-DC converter
Type	TEN 40-2412WIE
Weight	34g
Width	25.4mm
