TracoPower TDR 3-2423SM Compact DC/DC Converter 24VDC-15VDC 2 Outputs

TracoPower
Standard range
Order Code:

07-8140

Brand: TracoPower MPN: TDR 3-2423SM
Qty Unit Price (Ex VAT)
1+ £27.99
5+ £27.15
10+ £27.00
25+ £26.86
50+ £26.71
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
10 in stock, despatched in 4 working days

The TracoPower TDR 3-2423SM is a DC/DC converter with a 24 V DC input and dual 15 V DC output configuration. It supports outputs of ±15 V DC at 100 mA and delivers up to 3 W of power, making it ideal for efficient power supply applications in compact systems. This component is typically used in telecommunications and industrial electronics where regulated power supply conversion is needed.
Type DC/DC converter (print)
Connection Solder pins
Dim (L x W x H) 17.2 x 8.7 x 18.9 mm
Efficiency (max.) 83%
Height 18.9mm
Input voltage (max.) 36V DC
Insulation voltage 1600V DC
Length 17.2mm
Max. output current 100mA
Min. input voltage 18V DC
Misc Attribute TDR 3-2423SM
No. of outputs 2
Nominal voltage 24V DC
Operating temperature (max.) 85°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 100mA
Power 3W
Weight 4.5g
Width 8.7mm
