TracoPower TBLC 50-124 SMPSU 28V DC 2.1A 50W DIN-Rail Mounting

TracoPower
Order Code:

07-8125

Brand: TracoPower MPN: TBLC 50-124
Qty Unit Price (Ex VAT)
1+ £64.35
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 14/12/2025

TracoPower's TBLC 50-124 is a 50 W switched-mode power supply unit (SMPSU) with a 28 V DC output and 2.1 A current capacity. It's designed for PCB mounting with solder lugs, making it suitable for integration into circuit board power supply units. Typical applications include industrial electronics and control systems where reliable power conversion is essential.
Connection Screw terminal
Dim (L x W x H) 59.5 x 54 x 89.5 mm
Height 89.5mm
Input voltage (max.) 264V AC
Length 59.5mm
Max. operating temperature (derating) 55°C
Max. output current 2.1A
Min. input voltage 85V AC
Misc Attribute 2 closed
Number of Outputs 1
Operating temperature (max.) 70°C
Operating temperature (min.) -25°C
Output current (max.) - rounded 2.1A
Output current (min.) 0mA
Output voltage (max.) 28V DC
Output voltage (min.) 24V DC
Power 50W
Type SMPSU
Width 54mm
