TracoPower TBA1-1212E DC/DC converter 84mA 1W 1 output

TracoPower TBA1-1212E is a high-performance DC-DC converter designed for precise power regulation in electronic applications that require a single 84 mA output with an efficiency of 1 W. As a print converter, this model is suitable for direct installation onto circuit boards, offering reliable conversion and power isolation in environments requiring compact and robust power management solutions. Its applications are typically found in industrial, medical, and IT devices where maintaining stable DC output from varying input sources is critical. The TBA1-1212E ensures consistent voltage transformation, making it an ideal choice for engineers working on energy-sensitive projects that demand dependable power conversion technology. With its efficient design, this converter addresses the need for reducing electromagnetic interference and enhancing the longevity of sensitive electronic components.

Connection	Solder pins
Content	1
Dimensions	(L x W x H) 19.50 x 6 x 9.50 mm
Efficiency (max.)	80%
Height	9.50mm
Insulation Voltage	1500V DC
Length	19.50mm
Max. output current	84mA
Maximum Input Volage	13.20V DC
Maximum Operating Temperature	95°C
Minimum Input Volage	10.8V DC
No. of outputs	1
Operating temperature (min.)	-40°C
Output current (max.) - rounded	84mA
Output voltage (max.)	12.0V DC
Output voltage (min.)	12.0V DC
Power	1W
Product Type	DC/DC converter (print)
Type	TBA 1E
Weight	2.30g
Width	6mm
