TracoPower TBA 2-0512 DC/DC converter 165 mA 2 W 1 output

TracoPower TBA 2-0512 is a versatile DC-DC converter designed to efficiently transform direct current for various applications. With a power output of 2 W and capable of providing a steady current of 165 mA, this single-output device is well-suited for use in electronic systems where a stable and reliable power conversion is essential. Its compact form factor and highly efficient design make it ideal for printed circuit board (PCB) installations, where space and performance are critical considerations. Commonly employed in telecommunications, industrial control systems, and instrumentation, the TBA 2-0512 ensures consistent voltage regulation and is an excellent choice for applications demanding high reliability and precision in power delivery.

Connection	Solder pins
Content	1
Dimensions	(L x W x H) 19.60 x 7.60 x 10.20 mm
Efficiency (max.)	82%
Height	10.20mm
Insulation Voltage	1500V DC
Length	19.60mm
Max. output current	165mA
Maximum Input Volage	5.50V DC
Maximum Operating Temperature	90°C
Minimum Input Volage	4.5V DC
No. of outputs	1
Operating temperature (min.)	-40°C
Output current (max.) - rounded	165mA
Output voltage (max.)	12.0V DC
Output voltage (min.)	12.0V DC
Power	2W
Product Type	DC/DC converter (print)
Type	TBA 2
Weight	2.80g
Width	7.60mm
