TracoPower TBA 1-2411 DC/DC converter 200mA 1W 1 output

TracoPower TBA 1-2411 is a robust DC-DC converter designed to deliver a stable output of 1 watt with a maximum current of 200 milliamperes. Featuring a single output, this device efficiently converts direct current, making it ideal for applications requiring precise voltage regulation and isolation. The TBA 1-2411 operates with high efficiency, ensuring reliable performance in compact electronic systems such as telecommunications equipment, distributed power systems, and industrial control modules. Its compact form factor and print mounting capability make it a versatile choice for printed circuit board (PCB) integration. The converter's design is optimised for environments where space and power efficiency are crucial.

Output Voltage	5V DC
Power Rating	1W
Connection	Solder pins
Content	1
Dimensions	(L x W x H) 11.70 x 6 x 9.70 mm
Efficiency (max.)	79%
Height	9.70mm
Insulation Voltage	1500V DC
Length	11.70mm
Max. output current	200mA
Maximum Input Volage	26.4V DC
Maximum Operating Temperature	95°C
Minimum Input Volage	21.6V DC
No. of outputs	1
Operating temperature (min.)	-40°C
Output current (max.) - rounded	200mA
Output voltage (max.)	5.0V DC
Output voltage (min.)	5.0V DC
Power	1W
Product Type	DC/DC converter (print)
Type	TBA 1
Weight	1.60g
Width	6mm
