TracoPower TBA 1-0512E DC/DC converter 84mA 1W 1 output

TracoPower TBA 1-0512E is a compact DC-DC converter specifically designed to provide reliable power conversion with a single output channel. This versatile converter delivers an output current of 84 mA at 1 W, making it an ideal choice for applications requiring precise and efficient power management. Featuring a print-compatible design, the TBA 1-0512E is engineered for seamless integration into printed circuit boards (PCBs), commonly utilised in telecommunications, industrial automation, and distributed power architectures. Its robust construction ensures durability and performance in challenging environments, supporting engineers in maintaining system reliability. As a current rectifier, it facilitates the conversion of direct current sources into stable outputs, thus supporting various electronics applications with critical power conversion needs.

Output Voltage	12V DC
Power Rating	1W
Connection	Solder pins
Content	1
Dimensions	(L x W x H) 19.50 x 6 x 9.50 mm
Efficiency (max.)	82%
Height	9.50mm
Input voltage (max.)	5.50V DC
Insulation Voltage	1500V DC
Length	19.50mm
Max. output current	84mA
Min. input voltage	4.5V DC
No. of outputs	1
Operating temperature (max.)	95°C
Operating temperature (min.)	-40°C
Output current (max.) - rounded	84mA
Output voltage (max.)	12.0V DC
Output voltage (min.)	12.0V DC
Power	1W
Product Type	DC/DC converter (print)
Type	TBA 1E
Weight	2.30g
Width	6mm
