TracoPower TBA 1-0311 DC/DC converter 1W 200mA 1 output

TracoPower TBA 1-0311 is a high-performance DC-DC converter designed to provide efficient power conversion in electronic applications requiring stable and regulated output. This compact direct current converter has a power capacity of 1 watt and is rated to deliver up to 200 milliamperes of current through a single output, making it ideal for low power and space-constrained designs. The TBA 1-0311 ensures reliable operation with a robust PCB-mounted design, offering seamless integration into printed circuit boards. Its applications typically include isolated power solutions, telecom equipment, and distributed power architectures where precise voltage regulation is critical. With its reliable performance and easy installation, it is a suitable choice for engineers seeking dependable power management components.

Output Voltage	5V DC
Connection	Solder pins
Content	1
Dimensions	(L x W x H) 11.70 x 6 x 9.70 mm
Efficiency (max.)	76%
Height	9.70mm
Input voltage (max.)	3.63V DC
Insulation Voltage	1500V DC
Length	11.70mm
Max. output current	200mA
Min. input voltage	2.97V DC
No. of outputs	1
Operating temperature (max.)	95°C
Operating temperature (min.)	-40°C
Output current (max.) - rounded	200mA
Output voltage (max.)	5.0V DC
Output voltage (min.)	5.0V DC
Power	1W
Product Type	DC/DC converter (print)
Type	TBA 1
Weight	1.60g
Width	6mm
