Image Representative of Range

TE Connectivity 2-1393236-1 Relay 24V DC 1CO Industrial 1pc

Discontinued

The TE Connectivity 2-1393236-1 is a general-purpose relay designed for single pole double throw (SPDT) applications.

It handles a current of 6A with a coil voltage of 24V DC.

This relay is typically used in industrial control systems and automation equipment.

Its robust design ensures reliable performance in various electrical circuits.

Coil Voltage	24V DC
Contact Configuration	1CO (SPDT)
Coil Current	6a
Coil Power	170mW
Coil Resistance	3390Ω
Coil Type	Non-Latching
Coil Voltage (AC)	400v
Coil Voltage (DC)	24v
Connection	THT
Contact Current Rating	6a
Contact Material	AgSnO₂
Contact Plating	Gold
Creepage distance (coil/clips)	8mm
Current Rating	6a
Depth	5mm
Dimensions	(L x W) 28 mm x 5 mm
Length	28.0mm
Maximum Operating Temperature	85°C
Minimum Operating Temperature	-40°C
Misc Attribute	V23092-A1024-A201
Mount	Through Hole, PCB
Nominal Voltage	24V DC
Number of Contacts	1
Operate Time	12ms
Package Quantity	20
Package/Case	SIP
Packaging	Bulk
Power Consumption	170mW
Radiation Hardening	No
Ratings	IP67
Reach SVHC Compliant	Unknown
Relay Type	General Purpose
Release Time	5ms
RoHS Compliant	Yes
Series	7mA
Termination	PC Pin
Throw Configuration	SPDT
Type	Industrial relay
Voltage Rating (AC)	400v
Weight	6g
Width	5.0mm
