TE Connectivity 1-5380758-1 IC Socket Female 036-054 30 AU Unshrouded

MPN: 1-5380758-1
Brand: TE Connectivity
Order Code: 14-4697
Country of Origin: USA

RoHS Compliant

Inc VAT

Qty	Unit Price (Ex VAT)
400+	£0.475

Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT

Order in multiples of 400

Despatched within 5 working days - 3,595 in stock

Product Details
Quick Quote

TE Connectivity 1-5380758-1 is an unshrouded IC socket designed for easy integration.

This socket features a female connector with robust build quality.

It supports 30 AU with pin configurations ranging from 036 to 054.

Typically used in computing and telecommunications, it ensures reliable connectivity for integrated circuits.

Pitch	Not Applicable
Row Pitch	Not Applicable
Circuit Application	Power & Signal
Connector & Contact Terminates To	Printed Circuit Board
Connector System	Cable-to-Board
Contact Base Material	Beryllium Copper
Contact Current Rating	4a
Contact Current Rating (Max)	4
Contact Material	Copper
Contact Mating Area Plating Material Thickness	30
Contact Plating	Gold
Current Rating	5a
Depth	3.18mm
Length	6.65mm
Max Operating Temperature	258°C
Min Operating Temperature	-85°C
Mount	Surface Mount
Number of Contacts	1
Number of Rows	1
Operating Temperature Range	-85 – 257
Orientation	Straight
Package Quantity	2000
Packaging	Loose Piece
Packaging Method	Loose Piece
Packaging Quantity	2000
PCB Thickness	3.18mm
PCB Thickness (Recommended)	.031 – .125
Plating Thickness	30um
Radiation Hardening	No
Reach SVHC Compliant	Unknown
RoHS Compliant	Yes
Sealable	No
Termination	Press-Fit
Termination Method to PCB	Through Hole - Press-Fit
Termination Method to Wire & Cable	Solder
Type	IC Socket Female
Voltage Rating	60v
Wire Size	20 – 16
Wire/Cable Gauge	16AWG
Wire/Cable Type	Discrete
