TDK-Lambda KMD40-1212 KMD AC/DC PSU 12V 1.67A 40W Medical/Industrial Use

TDK-Lambda's KMD40-1212 AC/DC PSU provides a stable 12 V output at 1.67 A, delivering 40 W of power, and is suited for PCB mounting with convenient solder lugs. This printed circuit board power supply unit is ideal for equipping electronic circuits in various consumer and industrial applications. Its compact design and reliable performance make it an excellent choice for projects requiring efficient AC to DC conversion.

Number of Outputs	2
Output Power Max	40W
Output Voltage	12V
Mounting Type	PCB
Cooling	Convection
Dimensions	(L x W x H) 89 x 64 x 27 mm
Height	27mm
Input	Single-phase
Input Voltage Range[AC] / Vac	90 to 264
Input Voltage Range[DC] / Vdc	100 to 375
Length	89mm
Max. output current	1.67A
Maximum Operating Temperature	70°C
Operating temperature (min.)	-25°C
Option	Class II input
Output Current	1.67A
Output Power / W	40
Output Voltage Range[DC] / Vdc	Fixed Fixed
Package / Mounting	PCB mount
Protection Class	II
Rated Output Voltage[DC] / Vdc	0
Series	KM
SPEC ADDED	KM,PCB mount-Single-phase, Convection, 90 to 264 AC,Class II input,Fixed Fixed Vdc
Type	AC/DC PSU (print)
Weight	280g
Width	64mm
