TDK-Lambda KAS4-8 KAS Series AC/DC PSU 8V 0.5A 4W Flame-retardant

TDK-Lambda
Order Code:

10-7628

Brand: TDK-Lambda MPN: KAS4-8 EAN-13: 2050006628027
Qty Unit Price (Ex VAT)
1+ £26.71
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack order, lead time 11 days

The TDK-Lambda KAS4-8 AC/DC power supply unit (PSU) offers an output of 8 V, 0.5 A, and 4 W, suitable for PCB mounting with solder lugs. Acknowledged for its compact design, it is ideal for integrating into printed circuit boards for efficient power distribution. This PSU is typically used in electronic equipment requiring reliable, low-power AC to DC conversion.
Number of Outputs 1
Output Power Max 4W
Output Voltage 8V
Output Current 500mA
Mounting Type PCB
Cooling Convection
Dimensions (L x W x H) 37 x 27.5 x 17.5 mm
Height 17.5mm
Input Single-phase
Input Voltage Range[AC] / Vac 90 to 305
Input Voltage Range[DC] / Vdc 120 to 430
Length 37mm
Max. output current 0.5A
Operating temperature (max.) 70°C
Operating temperature (min.) -40°C
Option Class II input
Output Power / W 4
Output Voltage Range[DC] / Vdc Fixed
Package / Mounting PCB mount
Protection Class II
Rated Output Voltage[DC] / Vdc 8
Series KAS
SPEC ADDED KAS,PCB mount-Single-phase, Convection, 90 to 305 AC,Class II input,Fixed Vdc
Type AC/DC PSU (print)
Width 27.5mm
