TDK-Lambda DRL30-12-1 DRL Rail PSU 12V 2.1A 25.2W DIN Rail Mounted 1piece

TDK-Lambda
Order Code:

10-7600

Brand: TDK-Lambda MPN: DRL30-12-1 EAN-13: 4053199910434
Qty Was Unit Price (Ex VAT)
1+ £39.22 £34.10
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
11 in stock, despatched in 4 working days

The TDK-Lambda DRL30-12-1 is a rail mounted PSU (DIN) providing 12 V and 2.1 A with a total power of 25.2 W. This industrial power supply unit is ideal for applications requiring reliable power distribution within control panels and automation systems. Its compact design allows for easy installation on DIN rails.
Type Rail mounted PSU (DIN)
Output Voltage 12V
Output Current 2.1A
Number of Outputs 1
Power Rating 25.2W
Cooling Convection
Dim (L x W x H) 55.6 x 36 x 91 mm
Height 91mm
Input Single-phase
Input voltage (max.) 264V AC
Input Voltage Range[AC] / Vac 85 to 264
Length 55.6mm
Max. output current 2.1A
Max. temperature 85°C
Min. input voltage 85V AC
Min. temperature -40°C
Operating temperature (max.) 71°C
Operating temperature (min.) -25°C
Option Comply with Class 2 output per UL1310
Output Power / W 25.2
Output Voltage Range[DC] / Vdc 12 to 15
Package / Mounting DIN rail
Rated Output Voltage[DC] / Vdc 12
Series DRL
SPEC ADDED DRL,DIN rail-Single-phase, Convection, 85 to 264 AC,Comply with Class 2 output per UL1310,12 to 15 Vdc
Width 36mm
