TDK-Lambda DRL10-12-1 DRL Rail PSU DIN 12V 0.84A 10.08W 1piece 3kV AC Input

The TDK-Lambda DRL10-12-1 is a rail mounted power supply unit providing 12 V at 0.84 A, with a total power output of 10.08 W. This industrial power supply is suitable for DIN rail installation and is ideal for applications requiring reliable and efficient power solutions. It is typically used in various industrial and automation settings where compact and robust power supplies are essential.

Type	Rail mounted PSU (DIN)
Output Voltage	12V
Output Current	840mA
Number of Outputs	1
Power Rating	10W
Cooling	Convection
Dim	(L x W x H) 55.6 x 18 x 91 mm
Height	91mm
Input	Single-phase
Input Voltage Range[AC] / Vac	85 to 264
Length	55.6mm
Max. output current	0.84A
Maximum Input Volage	264V AC
Maximum Operating Temperature	71°C
Maximum Temperature	85°C
Min. temperature	-40°C
Minimum Input Volage	85V AC
Operating temperature (min.)	-25°C
Option	Comply with Class 2 output per UL1310
Output Power / W	10.08
Output Voltage Range[DC] / Vdc	Fixed
Package / Mounting	DIN rail
Rated Output Voltage[DC] / Vdc	12
Series	DRL
SPEC ADDED	DRL,DIN rail-Single-phase, Convection, 85 to 264 AC,Comply with Class 2 output per UL1310,Fixed Vdc
Weight	65g
Width	18mm
