TDK-Lambda CCG30-24-12D DC/DC Converter 24V 1.25A 30W 1 Output 1piece

TDK-Lambda
Order Code:

10-7588

Brand: TDK-Lambda MPN: CCG30-24-12D EAN-13: 2050006495681
Qty Was Unit Price (Ex VAT)
1+ £36.96 £32.44
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
81 available to back orderBack-order availability date - 12/04/2026

The TDK-Lambda CCG30-24-12D is a compact DC/DC converter that delivers 24 V at 1.25 A, providing 30 W power output. It efficiently serves applications requiring voltage conversion, such as industrial electronics and telecommunications. This single-output converter is ideal for printed circuit board installations where reliable DC power is needed.
Output Voltage 24V DC
Input Voltage Range 36V
Power Rating 30W
Output Current 1.25A
Connection Solder pins
Dim (L x W x H) 25.4 x 25.4 x 9.9 mm
Efficiency (max.) 89%
Enclosure DIP 6 (1x1 brick)
Height 9.9mm
Industry Standard Size 1x1 inch size
Input Voltage Range[DC] / Vdc 9 to 36
Isolation Isolated
Length 25.4mm
Max. output current 1.25A
Maximum Output Current / A 1.25 1.25
Maximum Output Power / W 30
Min. input voltage 9V
Nominal Input Voltage[DC] / Vdc 2024-12-01 00:00:00,45627
Number of Outputs 1
Operating temperature (max.) +85°C
Operating temperature (min.) -40°C
Output Voltage Range[DC] / Vdc Fixed Fixed
Package / Mounting PCB mount
Power 30W
Rated Output Voltage[DC] / Vdc 0
Series CCG
Terminal Style DIP
Type DC/DC converter (print)
Width 25.4mm
