Sunon PMD2412PMB1A Axial Fan 24V DC 322.73m³/h 120x120x38mm

Sunon manufactures the PMD2412PMB1A axial fan, which operates at 24 V DC and provides an airflow of 322.73 m³/h. Measuring 120 x 120 x 38 mm, this industrial fan is designed for component cooling and various applications requiring efficient ventilation. It is ideal for use in electronic equipment and industrial machinery cooling systems.

Type	Axial fan
Voltage	24 V (max)
Dimensions	(L x W x H) 120 x 120 x 38 mm
Air Flow	322.73m³/h
Bearing Type	Ball Bearing
Noise	54dB
Power Rating	760mA
RPM	4200 U/min
Cable Length	0.30m
Connection	Open end cable
Height	38mm
Length	120mm
Max. operating voltage	24V
Max. temperature	+70°C
Min. temperature	-10°C
Width	120mm
