Sunon DP201A2123HBT Axial Fan 230V AC 147.78m³/h 120x120x38mm

The Sunon DP201A2123HBT is an axial fan operating on 230 V AC, delivering an airflow of 147.78 m³/h. This fan measures 120 x 120 x 38 mm, making it suitable for compact spaces requiring effective cooling. It is typically used in industrial settings for component cooling and temperature regulation.

Type	Axial fan
Voltage	115 - 230 V
Dimensions	(L x W x H) 120 x 120 x 38 mm
Air Flow	147.78m³/h
Bearing Type	Ball Bearing
Noise	45dB
Power Rating	125mA
RPM	2750 U/min
Connection	Type C CEE 7/16 plug 2.8mm
Height	38mm
Length	120mm
Max. operating voltage	230V
Max. temperature	+70°C
Min. operating voltage	115V
Min. temperature	-10°C
Width	120mm
