Siemens 5SU13566KK13 RCBO 13A 30mA 230V 1P+N Type A 10kA C-Char 6A

Siemens manufactures the 5SU13566KK13, a residual current circuit breaker with a 13 A current rating and 0.03 A earth leakage sensitivity, suitable for 230 V systems. This device combines circuit breaking and residual current protection for enhanced safety. It is typically used to provide personal protection and prevent electrical shocks in residential and commercial installations.

Type	Switch
Current Rating	13A
Voltage Rating - AC	230V AC
Actuator Type	Toggle
Tripping Characteristics	B Curve
Ambient temperature during operating	N/A
Anti-nuisance tripping version	TRUE
Built-in depth	70mm
Concurrently switching neutral conductor	TRUE
Connectable conductor cross section multi-wired	0.75 - 35mm²
Connectable conductor cross section solid-core	0.75 - 35mm²
Current limiting class	3
Current Ratng	0.03A
Degree of protection (IP)	IP20
Depth	70mm
Differential current rating	0.03A
Dim	(W x H x D) 36 x 90 x 70 mm
Disconnection characteristic	Undelayed
Flush-mounted installation	true
Frequency	N/A
Height	90mm
Leakage current type	A
Misc Attribute	Switch-off description: without delay
Number of pins	2
Number of poles (total)	2
Number of protected poles	1
Overvoltage category	2
Pollution degree	2
Power loss	N/A
Product colour	Multicolour
Rated current	13A
Rated fault current	0.03A
Rated impulse withstand voltage Uimp	4
Rated insulation voltage Ui	264V
Rated short-circuit breaking capacity according to EN 61009	6
Rated short-circuit breaking capacity according to IEC 60947-2	15kA
Rated short-circuit breaking capacity Icn according to EN 61009-1	6
Rated voltage	230V
Surge current capacity	1kA
Switch-off Capacity	6
Voltage Rating	230V
Voltage type	AC
Weight	0
Width	36mm
Width in number of modular spacings	2
With interlocking device	TRUE
