Siemens 5SP38502 GAMMA RCCB 50A 230V/400V titanium white

The Siemens 5SP38502 Main RCCB is a residual current circuit breaker with a capacity of 50 A, suitable for 230 V and 400 V systems. It is typically used for protecting electrical installations from faults and providing safe cut-off in residential, commercial, and industrial applications. This device ensures enhanced electrical safety by detecting and interrupting residual currents.

Type	Main RCCB
Current Rating	50A
Voltage Rating - AC	230V AC
Tripping Characteristics	E
Compatible with (details)	SENTRON
Concurrently switching neutral conductor	FALSE
Construction size according to DIN 43880	N/A
Current Ratng	50A
Degree of protection (IP)	IP40
Depth	89.5mm
Dim	(W x H x D) 81 x 151.3 x 89.5 mm
Factory colour	Grey
Frequency	50Hz
Height	151.3mm
Mounting method	Busbar
Number of pins	3
Number of Poles	3
Overvoltage category	2
Pollution degree	3
Rated current	50A
Rated insulation voltage Ui	690V
Rated surge voltage invariability	6kV
Rated switching capacity	25A
Rated voltage	400V
Voltage Rating	400V
Width	81mm
