Siemens 3NA6224 LV HRC Fuse system NH2 80A 500V insulated grips

Image Representative of Range

Siemens 3NA6224 LV HRC Fuse system NH2 80A 500V insulated grips

Siemens
Order Code:

06-8137

Brand: Siemens MPN: 3NA6224 EAN-13: 4001869071510
Qty Unit Price (Ex VAT)
1+ £30.71
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack order, lead time 11 days

The Siemens 3NA6224 is a fuse holder inset designed for a Fuse Size 2, handling up to 80 A and 500 V, ensuring reliable electrical safety in low voltage applications. Manufactured by Siemens, this low voltage HRC fuse component is part of a knife blade fuse system, known for its robust protection in industrial and commercial settings. Typical applications include use in electrical distribution systems and machinery protection.
Type Fuse holder inset
Fuse Size 2
Current Rating 80A
Voltage Rating - AC 500V
Voltage Rating - DC 440
Duty class gG
Fuse construction type according to IEC 60269 N/A
Insulated metal gripping lugs (IMGL) true
Nominal Voltage 500V
Power loss at rated current 6.8
Rated current 80A
Rated switching capacity 120A
Rated switching capacity AC N/A
Rated switching capacity DC N/A
Rated voltage AC 500V
Rated voltage DC 440V
Switch-off capacity 120kA
Type of fuse status indicator Combination fuse status indicator
Utilization category according to IEC 60269 gL/gG (cable protection/equipment protection)
Voltage type AC/DC
Width 47.2mm
