Self Electronics SLD75-12VL-E LED Transformer 75W 12V DC Dimmable Furniture Safe

Image Representative of Range

Self Electronics SLD75-12VL-E LED Transformer 75W 12V DC Dimmable Furniture Safe

Self Electronics
Standard range
Order Code:

10-5672

Brand: Self Electronics MPN: SLD75-12VL-E EAN-13: 4021087039734
Qty Unit Price (Ex VAT)
1+ £50.31
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
6 in stock, despatched in 4 working days

The Self Electronics SLD75-12VL-E LED transformer provides a constant voltage of 75 W and outputs between 1 - 6.25 A at 12 V DC. This dimmable transformer is approved for use on furniture and includes surge protection. It is typically used to power LED strips and other LED lighting applications.
Type LED transformer
Connection Screw terminal
Dim (L x W x H) 185 x 60 x 31 mm
Height 31mm
Input voltage (max.) 264V AC
IP rating IP20
Length 185mm
Max. output current 6.25A
Max. power 75W
Max. temperature +45°C
Min. input voltage 198V AC
Min. temperature -10°C
Misc Attribute Constant voltage
No. of inputs 1
No. of outputs 1
Operating voltage 230V AC
Output current (max.) - rounded 6.25A
Output current (min.) 1A
Output voltage (max.) 12V DC
Power range 75 W (max)
Protection class II
Test mark CE; SELV; MM; ENEC
Weight 306g
Width 60mm
