Powerful 2000W motor. Features integral aluminium workpiece supports which store inside the aluminium base to save space and prevent loss. Fitted with a 40-tooth TCT blade for fresh wood. Can be fitted with Model No. SMS255B multipurpose blade for use with mild steel, aluminium and wood with nails. Features double slides which can be locked at different lengths allowing greater control over the desired length of cut. Max cut of up to 315mm at 0° bevel. Unit is also fitted with a laser guide to help produce accurate cuts. Supplied with workpiece clamp, dust extraction bag and fitted with carry handle. Features locking increments at mitre stops 0°,15°, 22.5°, 31.6°, 45° Left & Right.
- Powerful 2000W motor.
- Features integral aluminium workpiece supports which store inside the aluminium base to save space and prevent loss.
- Fitted with a 40-tooth TCT blade for fresh wood.
- Can be fitted with Model No. SMS255B multipurpose blade for use with mild steel, aluminium and wood with nails.
- Features double slides which can be locked at different lengths allowing greater control over the desired length of cut.
- Max. Cut of up to 315mm at 0° bevel.
- Unit is also fitted with a laser guide to help produce accurate cuts.
- Supplied with workpiece clamp, dust extraction bag and fitted with carry handle.
- Features locking increments at mitre stops 0°,15°, 22.5°, 31.6°, 45° Left and Right.
- Cross Cut (0° Bevel x 0° Table): 90 x 315mm.
- Mitre Cut (0° Bevel x 45° Table): 90 x 215mm.
- Bevel Cut (45° Bevel x 0° Table): 40 x 215mm.
- Model No. SMS255
| Blade Size(s) |
255 x 2.8 x Ø30mm |
| Blade Speed(s) |
Max Speed 7000rpm |
| Cutting Specification Cross Cut (0° Bevel x 0° Table) |
90 x 315mm |
| Cutting Specifications Bevel Cut (45° Bevel x 0° Table) |
40 x 215mm |
| Cutting Specifications Mitre Cut (0° Bevel x 45° Table) |
90 x 215mm |
| Dust extraction port |
ID Ø35mm/OD Ø43mm |
| Motor Power |
2000W |
| Nett Weight |
16.4kg |
| No-Load Speed |
5000rpm |
| Positive Mitre Lock |
0°,15°, 22.5°, 31.6°, 45° Left and Right |
| Supply |
230 |
