The Schneider Electric A9F03101 is a 1 A miniature circuit breaker designed for over-current and short-circuit protection at 230 V. Primarily used for installation protection, this circuit breaker is essential for safeguarding electrical circuits in residential and commercial buildings. The iC 60 model ensures reliable switching and protection, maintaining the integrity of your electrical systems.
| Type |
Circuit breaker |
| Voltage Rating - AC |
230V AC |
| Tripping Characteristics |
B Curve |
| Additional equipment possible |
true |
| Ambient temperature during operating |
-35 - 70°C |
| Built-in depth |
44.5mm |
| Concurrently switching neutral conductor |
false |
| Connectable conductor cross section multi-wired |
1 - 16mm² |
| Connectable conductor cross section solid-core |
1 - 25mm² |
| Current limiting class |
3 |
| Current Ratng |
1A |
| Degree of protection (IP) |
IP20 |
| Dim |
(L x W x H) 78.5 x 18 x 91 mm |
| Explosion-proof |
false |
| Factory colour |
White |
| Flush-mounted installation |
false |
| Frequency |
50 - 60Hz |
| Height |
91mm |
| Length |
78.5mm |
| Number of pins |
1 |
| Number of Poles |
1 |
| Number of poles (total) |
1 |
| Number of protected poles |
1 |
| Overvoltage category |
4 |
| Pollution degree |
3 |
| Power loss |
2.3W |
| Rated current |
1A |
| Rated impulse withstand voltage Uimp |
6kV |
| Rated insulation voltage Ui |
500V |
| Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V |
6kA |
| Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V |
N/A |
| Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V |
50kA |
| Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V |
N/A |
| Rated voltage |
230V |
| Voltage Rating |
230V |
| Voltage type |
AC/DC |
| Width |
18mm |
| Width in number of modular spacings |
1 |
