Rohde & Schwarz 3658.6470.04 R&S®UDS500-G Bench Multimeter is a highly accurate digital display instrument designed for precise measurement tasks in engineering environments. As , it delivers advanced measurement capabilities across multiple parameters, including voltage, current, and resistance, with high resolution and stability. This bench multimeter is ideal for applications in research and development, quality control, and electronic testing where precision and reliability are critical. Engineered to meet the demanding requirements of modern laboratories, the R&S®UDS500-G provides comprehensive data analysis tools, ensuring technicians and engineers can conduct thorough evaluations efficiently. With its robust build and sophisticated functionality, it supports a wide range of electrical and electronic assessments.
| Type |
R&S®UDS500-G |
| A AC reading range (min.) |
20mA |
| A DC reading range (max.) |
10A |
| Amperage reading range AC (max.) |
10A |
| Amperage reading range DC (min.) |
20mA |
| Basic accuracy |
0.015% |
| Current reading |
AC/DC |
| Dimensions |
(L x W x H) 291 x 222 x 97 mm |
| Display |
Digital |
| Frequency Range |
5 Hz - 100kHz |
| Height |
97mm |
| Length |
291mm |
| Measurement type (details) |
True RMS |
| Power supply (details) |
115 - 230V AC |
| Product Type |
Bench multimeter |
| Reading range - capacity |
5 nF - 500 μF |
| Reading range - resistance |
200 Ω - 250mΩ |
| Temperature |
Resolution 0.1°C |
| V AC reading range (max.) |
750V |
| V AC reading range (min.) |
250mV |
| Voltage DC reading range (max.) |
1000V |
| Voltage metering |
AC/DC |
| Voltage reading range DC (min.) |
250mV |
| Weight |
2.7kg |
| Width |
222mm |
