Rohde & Schwarz 3658.6470.02, also referred to by the alternate description 3443516, is that embodies the precision and reliability expected from advanced measuring instruments. This R&S®UDS500 bench multimeter features a high-resolution graphics display, enabling detailed visualisation of complex measurements for enhanced analysis in laboratory and industrial environments. It is designed for a wide range of engineering applications, including circuit testing, product development, and quality assurance processes, where accurate measurement of electrical parameters is critical. Utilising state-of-the-art technology, the multimeter provides engineers with essential data for precise monitoring and evaluation, supporting tasks that demand high-precision results.
| Type |
R&S®UDS500 |
| A AC reading range (min.) |
20mA |
| A DC reading range (max.) |
10A |
| Amperage reading range AC (max.) |
10A |
| Amperage reading range DC (min.) |
20mA |
| Basic accuracy |
0.015% |
| Current reading |
AC/DC |
| Dimensions |
(L x W x H) 291 x 222 x 97 mm |
| Display |
Digital |
| Frequency Range |
5 Hz - 100kHz |
| Height |
97mm |
| Length |
291mm |
| Measurement type (details) |
True RMS |
| Power supply (details) |
115 - 230V AC |
| Product Type |
Bench multimeter |
| Reading range - capacity |
5 nF - 500 μF |
| Reading range - resistance |
200 Ω - 250mΩ |
| Temperature |
Resolution 0.1°C |
| V AC reading range (max.) |
750V |
| V AC reading range (min.) |
250mV |
| Voltage DC reading range (max.) |
1000V |
| Voltage metering |
AC/DC |
| Voltage reading range DC (min.) |
250mV |
| Weight |
2.7kg |
| Width |
222mm |
