Recom 10002367 RO-053.3S 1W DC/DC Converter 5V In 3.3V Out

Order Code:

49-7120

Copy to clipboard

( Write a review )

Brand: Recom Copy to clipboard MPN: RO-053.3S Copy to clipboard

RoHS Compliant
Country of Origin: Taiwan

Report an error

Discontinued

Product Details
Data Sheets

A Recom unregulated DC/DC converter from the RO series. This single output converter is supplied in the standard SIP4 package style. The converter has been designed to offer exceptionally high efficiency at low loads, an extended operating temperature range and low deviation (10% to 100% load). It is ideal for use in applications with a restricted energy budget, and industrial applications where a high efficiency level is required.

Accuracy: 1%
Grid pitch: 2.54mm
Insulation voltage: 1000V DC
Product Specifications: Ripple: (20MHz bandwidth) 100mVpp
Output current: 303mA
Input voltage: 5V
Output voltage: 3.3V
Specification: SIP4
Efficiency: 80%
Operating Temperature from -40°C to +85°C
Dimensions: 11.5(L) x 6.0(W)mm
Type: DC to DC Converter RO Series
Manufacturer's part: RO-053.3S

Mounting Style	SIP-4
Number of Outputs	1
Output Voltage Min	N/A
Output Voltage Max	3.3V
Output Current Min	N/A
Output Current Max	303mA
Power Rating	1W
Supply Voltage Range	5V
Temperature Range	-40 to +85°C
