Rautronic FB0828127B Ribbon & Flat Cables, grey, 1m, 0.08mm² cross section

Rautronic FB0828127B, FBL 08P AWG28 DIN47100, is a grey ribbon and flat cable distinguished by its 0.08mm² cross-sectional area and 1-metre length. This cable is designed to meet the rigorous requirements of modern electronic assemblies, ensuring reliable performance in applications demanding precise signalling and fractional conductance control. Its construction adheres to DIN47100 standards, making it well-suited for use in data communication, signal transmission, and compact circuit designs where space efficiency and high-density configurations are paramount. Suitable for internal wiring of electronic devices, the cable’s flexible and flat form factor is optimal for routing in constrained spaces or layered installations. With its robust design and compliance with standardised colour coding for easier identification, this ribbon cable is ideal for complex wiring schemes in industrial and commercial electronic systems.

AWG	28
Conductor Cross Section	0.09mm²
Colour	Multicoloured
Length	1m
Type	Ribbon cable
Content	Sold per metre
Halogen free	No
Height	1mm
Insulation Material	PVC
Material (details)	Copper tin-plated
No. of leads	8
Nominal Voltage	300V
Shielded	No
Test voltage	2kV
Weight	0.016kg
Width	9.89mm
