R-TECH 524435 12V Buzzer (Low Profile) 11.6mm dia

R-TECH
Standard range
Order Code:

52-4435

Brand: R-TECH MPN: 524435 EAN-13: 5053556005550
Qty Unit Price (Ex VAT)
1+ £1.14
25+ £0.959
50+ £0.863
100+ £0.797
500+ £0.740
1000+ £0.691
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
Out of stock6,000 due on 24/11/2025


A PCB mounting buzzer with a loud but pleasant 85dB tone, operating from a 12V DC supply. The buzzer is only 7.5mm high when mounted on the PCB. It will work with a supply voltage ranging from 8 to 15V DC. Supply polarity is marked on the bottom of the top of the housing as an aid to installation. The case is finished in black.


  • The base of the device is potted to maximise protection against flux contamination
  • Masking label is included over the sound emission hole to permit board cleaning
  • Encapsulated in a low profile housing making them particularly suitable for inclusion in miniature electronics instrumentation
  • Supplied with PCB pins for direct mounting to PCBs
  • Small / low profile design
  • Compact rich sound
  • Pitch 7.6mm
  • Application: cellular phones, pagers, communication equipment, computers, household appliances, security of electronic devices
  • Dimensions 11.6 x 11.6 x 7.5mm
    • Type Buzzer
