PTR Hartmann 54791030422F Spring-loaded Terminal 0.75mm² 3 Pins Grey

Image Representative of Range

PTR Hartmann 54791030422F Spring-loaded Terminal 0.75mm² 3 Pins Grey

PTR
Standard range
Order Code:

06-2910

Brand: PTR MPN: 54791030422F
Qty Unit Price (Ex VAT)
1+ £0.477
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
192 in stock, despatched in 4 working days

PTR Hartmann's 54791030422F is a spring-loaded terminal designed for printed circuit boards, offering a connection capacity of 0.75 mm² with three pins. The terminal block, in basalt grey, is ideal for secure and reliable electrical connections in electronic applications. Typical uses include providing connections in various PCB assemblies where compact and efficient wiring is essential.
AWG (min.) 26
AWG max. 18
Connector orientation Parallel (to the PCB)
Contact material Brass
Cross section (flexible) (max.) 0.75mm²
Cross section (flexible) (min.) 0.14mm²
Cross section (inflexible) (max.) 0.75mm²
Cross section (inflexible) (min.) 0.14mm²
CS 2.54mm
Factory colour Basalt grey
Height 13.70mm
Length 10.16mm
Manufacturer part # 54791030422F
Min. stripping length 10mm
Misc Attribute AKZ4791/3KD-2.54-H
No. of rows 1
Nominal current 6A
Nominal current - rounded value 6A
Nominal voltage 150V
Number of pins 3
Pins per row 3
Series AKZ4791
Stripping length (max.) 10mm
Type Spring-loaded terminal
Width 16.20mm
Wire protection Yes
