PTR Hartmann 54191030051F Spring-loaded Terminal 3-Pin 0.75mm² Pebble Grey

Image Representative of Range

PTR Hartmann 54191030051F Spring-loaded Terminal 3-Pin 0.75mm² Pebble Grey

PTR
Order Code:

06-2895

Brand: PTR MPN: 54191030051F EAN-13: 2050001585080
Qty Unit Price (Ex VAT)
20+ £0.219
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
181 in stock, despatched in 4 working days

The PTR Hartmann 54191030051F is a spring-loaded terminal designed for printed circuit boards with a wire cross-section of 0.75 mm² and accommodates 3 pins. This pebble grey connector is ideal for secure and reliable electrical connections in compact electronic devices. Typically used in electronics assembly, it ensures robust screw terminal connectivity in various applications.
Pitch 2.5mm
No. of Ways 3
Mounting Type Through Hole
Mounting Direction Vertical
Wire Gauge (AWG) 26 to 20 AWG
Wire Termination Screwless
AWG (min.) 26
AWG max. 20
Colour Grey
Connector orientation At an angle (to the PCB)
Contact Material Bronze
Cross section (flexible) (max.) 0.75mm²
Cross section (flexible) (min.) 0.14mm²
Cross section (inflexible) (max.) 0.75mm²
Cross section (inflexible) (min.) 0.14mm²
CS 2.50mm
Current Rating 2A
Factory colour Pebble grey
Height 12.00mm
Length 9.00mm
Min. stripping length 9mm
Misc Attribute AK4191/3KDVP-2.5
No. of Levels 1
Pins per row 3
Series AK4191
Stripping length (max.) 9mm
Type Spring-loaded terminal
Voltage Rating 300V
Width 16.60mm
Wire protection Yes
