PTR Hartmann 50692080021E Screw Terminal 0.75 mm² 8 Pins Green 1pc

Image Representative of Range

PTR Hartmann 50692080021E Screw Terminal 0.75 mm² 8 Pins Green 1pc

PTR
Order Code:

06-2825

Brand: PTR MPN: 50692080021E EAN-13: 2050001584687
Qty Unit Price (Ex VAT)
5+ £0.935
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
466 in stock, despatched in 4 working days

The PTR Hartmann 50692080021E is a green screw terminal with a capacity of 0.75 mm² and has 8 pins. Manufactured by PTR Hartmann, this PCB connector is ideal for securely attaching wires to printed circuit boards. Common applications include use in electronic devices and equipment for signal and power supply connections.
No. of Ways 8
No. of Levels 1
Voltage Rating 150V
Current Rating 7A
Actuation direction Perpendicular (to the PCB)
AWG (min.) 30
AWG max. 18
Connector orientation Parallel (to the PCB)
Contact Material Brass
Cross section (flexible) (max.) 0.75mm²
Cross section (flexible) (min.) 0.14mm²
Cross section (inflexible) (max.) 0.75mm²
Cross section (inflexible) (min.) 0.14mm²
CS 2.54mm
Factory colour Green
Height 12.00mm
Length 6.50mm
Min. stripping length 4mm
Misc Attribute AKZ692/8-2.54-V-GRÜN
Pins per row 8
Series AKZ692
Stripping length (max.) 4mm
Type Screw terminal
Width 20.72mm
Wire protection Yes
