Phoenix Contact 3212142 Push-In Terminal 12.2 mm Blue 1pc Tool-free

The Phoenix Contact 3212142 is a blue, 12.2 mm quick-connect serial terminal designed for switchboard applications. It facilitates seamless electrical continuity in wiring systems with its efficient quick-connect feature. Ideal for use in industrial control panels and electrical distribution systems.

Type	Continuity
Pitch	12.2 mm
Termination	Push-in Cage clamp
Width	12.2mm
Wire Gauge (mm²)	25mm²
AWG (min.)	20
Clamp width	12.2mm
Closing plate required	true
Colour	Blue
Connectable conductor cross section fine-strand with cable end sleeve	0.5 - 0.5mm²
Connectable conductor cross section fine-strand without cable end sleeve	0.5 - 25mm²
Connectable conductor cross section multi-wired	- - -mm²
Connectable conductor cross section solid-core	0.5 - 25mm²
Connection	Quick-connect
Cross section (flexible) (min.)	0.5mm²
Cross section (inflexible) (min.)	0.5mm²
Current Rating	30A
Depth	52.6mm
Dim	(L x W x H) 75.4 x 12.2 x 52.6 mm
Explosion-tested version Ex e	N/A
Flammability Rating	V0
Height	52.6mm
Industrial packaging	No
Inflammability class of insulation material according to UL94	V0
Internally connected stages	true
Length	75.4mm
Material insulation body	Other
Misc Attribute	PT 16 N BU
Mounting method	DIN rail (top hat rail) 35 mm
Nominal Voltage	1000V
Number of clamp positions per level	2
Number of levels	1.0
Number of Pins	2
Number of Rows	1
Operating Temperature	-60 - 110°C
Rated current In	76A
Rated voltage	1000V
Stripping length (max.)	18mm
Suitable for conductor material	Aluminium/copper
Type of electrical connection 1	Other
Type of electrical connection 2	Other
Wire Gauge (AWG)	6
